Physical Features | Mdoel | RCO7067 |
Material | PET/Aluminum Foil/Foam | |
Dimensions | 60 x 25 x 1 mm(L x W x T) | |
Working Temp | -40~+85℃ | |
Survive Temp | 23±3 ℃ | |
Survival Humidity | 50±15 %RH | |
IP Rating | IP68,test for 5 hours at 1m deep water | |
RFID Features | RFID Standard | EPC C1G2 (ISO18000-6C) |
Chip Type | NXP Ucode 9 | |
Memory | User -N/A; EPC - 96 bits; TID - 96 bits | |
Read Range(Fixed Reader) | FCC: 5.2 m, onmetal | |
Read Range(Fixed Reader) | ETSI: 4.4 m, onmetal | |
Other Features | Data Storage | > 10 years |
Re-write | 100000 times | |
Installation | Adhesive | |
Support Printer | SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc. | |
Customization | Logo, parcoge/QR coae, number printing, encoding, antenna design, etc. | |
Package | Reel core inner diameter: 76.2 mm / 3" , Outside diameter < 220 mm / 8.7", 500pcs/roll. |
|
Application | Metallic container tracking | Equipment& device tracking Warehouse shelf Management | IT asset tracking, etc. |
